Apartment door station ETA 809 with doorbell for 9 apartments
Aluminum Apartment Building Doorbell Panel 809 EV1 – 9 Units | Elegant Flush-Mount Aluminum Doorbell Plate
The 809 EV1 apartment building doorbell panel is the ideal solution for large multi-family buildings with up to nine units. Its housing, made of silver anodized aluminum, not only offers a modern look but also reliably protects against weather and corrosion – perfect for long-term outdoor use.
Each button is equipped with an integrated nameplate and can be illuminated with an optional festoon bulb. This ensures your name remains clearly legible, even in the dark.
Note:
Please order the flush-mount box separately (Item No. 55889)
Technical Data:
Material: Aluminum, silver anodized
Shape / Dimensions: Rectangular (264 x 121 mm)
Mounting Type: Flush-mount (required flush-mount box: Item No. 55889)
Doorbell Buttons: 9 x Push buttons with nameplate
Lighting: Optional with festoon bulb (not included, Item No. 51016 or 51037 – 1 required per button)
Switching Capacity AC: Max. 24 V AC, 5 mA – 1.5 A / 24 VA
Switching Capacity DC: Max. 24 V DC, 5 mA – 1.0 A / 12 W
Mounting Holes: 16 mm from the outer edge
Operating Temperature: -4 °F to +122 °F (-20 °C to +50 °C)
Number of Housing Units: 9
Special Features:
Robust design made of corrosion-resistant aluminum
Generously sized buttons with writable name field
Optional lighting for better visibility at night
Discreet flush-mount installation for a sleek and elegant look
Ideal for large apartment complexes or commercial buildings
Scope of Delivery:
Doorbell panel 809 EV1 with 9 push buttons and nameplates (festoon bulbs and flush-mount box not included)
Recommended Accessories (sold separately):
Flush-Mount Box for flush-mount installation: Item No. 55889
Festoon Bulbs for nameplate illumination: Item No. 51016 or 51037 (1 per button)
Other optional components: Doorbell Transformers or Electronic Chimes
Order now – for a high-quality and durable doorbell solution for your building facade.
Technical data
| Length: | 5.4 cm |
|---|---|
| Width: | 12.1 cm |
| Height: | 26.5 cm |
| Color: | Aluminium |
| Color value: | EV1 |
| Material: | Aluminium |
| Weight: | 400.00 gm |
