Floor plate ETA 867 with doorbell for 12 apartments

Two-Row Aluminum Floor Panel 867 EV1 – 12-Button Doorbell Panel with Separate Light Plate | Robust Solution for Large Apartment Buildings

The floor panel ETA 867 EV1 is ideally suited for residential buildings with up to 12 units and also offers a separate light plate, which can be used, for example, for the house number, a logo, or other labeling. The smooth, silver anodized aluminum surface reliably protects against corrosion and weather.

Note:
Flush-mount box must be ordered separately (Item No. 55897)

Technical Data:

Material: Aluminum, silver anodized
Dimensions (W x H): 216 x 202 mm
Shape: Rectangular
Mounting Type: Flush-mount
Required Flush-Mount Box: UPK 867 (Item No. 55897)
Doorbell Buttons: 12 x Surface-mount buttons with nameplate
Light Plate: 1 x separate field for individual labeling (e.g., house number or building name)
Illumination: Optional with festoon bulbs (not included, Order No. 51016 or 51037 – 1 each per button or light plate)
Switching Capacity AC: Max. 24 V AC, 5 mA – 1.5 A / 24 VA
Switching Capacity DC: Max. 24 V DC, 5 mA – 1.0 A / 12 W
Mounting Holes: 16 mm from the outer edge
Temperature Range: -20 °C to +50 °C

Special Features:

12 Buttons for Housing Units + 1 Separate Light Plate
High-Quality Aluminum Housing – durable, weatherproof and visually appealing
Combinable with Lighting – for better visibility in the dark
Clear, Functional Design with structured name labeling
Easy Installation thanks to standardized drilling distances

Scope of Delivery:
Floor panel ETA 867 EV1 with 12 surface-mount buttons and 1 light plate (without flush-mount box and festoon bulbs)

Accessories Available Separately:

Flush-Mount Box: UPK 867 (Item No. 55897)
Festoon Bulbs for Illumination: Item No. 51016 or 51037
Additional Components: Doorbell Transformer, Chime Systems

The ideal solution for larger residential complexes that combine a uniform, high-quality appearance with practical functionality.
